Feature
•Fiber embedded,
no polishing and epoxy
•Highly
stable and reliable performance
•High
success rate design and technology
•Reusable
termination capability
•Use high
precision and quality zirconia ferrule
•Comply with IEC
and RoHS
•Flammability
Grade: UL94-V0
Specifications
Item No. |
Item Name |
Spec. Value |
1 |
Insertion Loss (dB) |
Max.≤0.5dB, Typical≤0.3dB |
2 |
Return Loss (dB) |
Max.APC≤-50dB, Typical≤-55dB Max UPC≤-40dB, Typical≤-45dB |
3 |
Ferrule End Face |
A Zone no scratches at 400X |
4 |
3D Interferometry |
Complies to IEC 2009 |
5 |
Average Assembling Time |
≤ 3 min |
6 |
First-Time Done Yield Rate |
≥ 95% |
7 |
Re-Operation Times |
Max. 5 times |
8 |
Repeatability (±0.2dB) |
≥ 90% |
9 |
Appearance |
No Defects |
Application:
FTTH network
Fiber optic cable distribution network
