Applicable connector types

SC

Polished types

APC, PC

Applicable fiber types

Single mode, Multimode

Applicable cable types

2mm or 3mm round cable
2mm x 3mm or 1.6mm x 2mm flat cable

Optical performance

APC: Insertion loss ≤0.3dB, Return loss ≥65dB
PC: Insertion loss ≤0.3dB, Return loss ≥50dB
Multimode: Insertion loss ≤0.2dB, Return loss ≥25dB

Repeatability

>50 times

Traction cord

10N, 120sec

Fall

50cm, 10 times

Vibration

10 to 55Hz, 0.75mm p-p, 90min

Cold

-40°C, 96h

Dry heat

75°C, 96h

Temperature cycle

-40°C to 75°C, 16 cycles
